Products Charge Controllers PR 0303
  • Description

    The Steca PR 0303 and PR 0505 solar charge controllers are optimally suited for use in small solar home systems.
    Lights, radios or small television sets, for instance, can be operated
    without issue. All loads can be switched off using the manual load switch on the controller. The extremely low own consumption makes the Steca PR especially suitable for professional applications in telecommunications and traffic management technology. Since this is a serial controller, it is extremely flexible in the type of power source that can be connected. The electronic fuse makes the controller completely maintenance-free and robust.

    Specification

    Product No. R1016
    Characterisation of the operating performance:
    System voltage 12 V
    Own consumption 3 mA
    DC input side:
    Open circuit voltage solar module < 47 V
    Module current 3 A
    DC output side:
    Load current 3 A
    Reconnection voltage (LVR) 12.5 V
    Deep discharge protection (LVD) 11 V … 11.5 V
    Battery side:
    End of charge voltage 13.7 V
    Boost charge voltage 14.4 V
    Set battery type gel
    Operating conditions:
    Ambient temperature -25 °C … +50 °C
    Fitting and construction:
    Terminal (fine / single wire) 6 mm² / 10 mm² - AWG 10 / 8
    Degree of protection IP 32
    Dimensions (X x Y x Z) 146 x 90 x 33 mm
    Weight 160 g

    Technical data at 25 °C / 77 °F

    Inverters must not be connected to the load output.

  • Product image

    PR 0303
    PR 0303

    Download

    Steca - PR 0303 0505.pdf (588.1 KiB)
