Description
The Steca Solsum F-Line continues the huge success of one of the most used SHS controllers. With a power range of up to 10 A at automatically recognized 12 V or 24 V it fits to a system sizes of maximum 240 W.
The circuit board is completely electronically protected and with the LED user interface it is easy to check the battery state of charge at any time. Large terminals guarantee a simple connection of solar panels, battery and load. The Steca Solsum F works on PWM as a low loss series controller.
Specification
Product No. R1019 Characterisation of the operating performance: System voltage 12 V (24 V) Own consumption < 4 mA DC input side: Open circuit voltage solar module < 47 V Module current 8 A DC output side: Load current 8 A Reconnection voltage (LVR) 12.4 V … 12.7 V (24.8 V … 25.4 V) Deep discharge protection (LVD) 11.2 V … 11.6 V (22.4 V … 23.2 V) Battery side: End of charge voltage 13.9 V (27.8 V) Boost charge voltage 14.4 V (28.8 V) Set battery type gel Operating conditions: Ambient temperature -25 °C … +50 °C Fitting and construction: Terminal (fine / single wire) 4 mm² / 6 mm² - AWG 12 / 9 Degree of protection IP 31 Dimensions (X x Y x Z) 145 x 100 x 30 mm Weight approx. 150 g Technical data at 25 °C / 77 °F
Adjustable via Steca PA RC100: reconnection voltage, deep discharge protection, end of charge voltage, boost charge voltage, battery type
Inverters must not be connected to the load output -
Product image
Solsum 8.8 Download
