Products Inverter Off Grid Solarix PI 1200
  • Description

    In developing the Solarix PI sine wave inverter, Steca has brought about some innovations which are unprecedented in this form. These are, above all, parallel connection, the novel operating concept which uses a single rotary switch, direct communication in order to calculate the state of charge (SOC) with Steca Tarom and Steca Power Tarom, and the electronic fuse. Furthermore, our many years of experience have come into play for deploying these inverters specifically in photovoltaic systems. This comes through, for instance, in the way that a most diverse range of appliances is provided with a low operating consumption and a stable energy supply.

    Specification

    Product No. I1206
    Inverter type PI 1200
    Number of inverters 1 / 0
    Characterisation of the operating performance:
    System voltage 48 V
    Continuous power 900 VA
    Power 30 min. 1,100 VA
    Power 100 sec. 1,400 VA
    Power 5 sec. 3,000 VA
    Power asymmetric 500 VA
    Max. efficiency 94 %
    Own consumption standby / ON 0.7 W / 10 W
    DC input side:
    Battery voltage 42 V … 64 V
    Reconnection voltage (LVR) 50 V
    Deep discharge protection (LVD)* 42 V
    AC output side:
    Output voltage 230 V AC +/-10 %
    Output frequency 50 Hz
    Load detection (standby) adjustable: 2 W ... 50 W
    Safety:
    Protection class II (double insulated)
    Electrical protection reverse polarity battery, reverse polarity AC, over voltage, over current, over temperature
    Operating conditions:
    Ambient temperature -20 °C … +50 °C
    Fitting and construction:
    Cable length battery / AC 1.5 m / 1.5 m
    Cable cross-section battery / AC 16 mm² / 1.5 mm²
    Degree of protection IP 20
    Dimensions (X x Y x Z) 212 x 395 x 130 mm**
    Weight 9 kg**

    * Data communication with Steca Power Tarom in dependence of Steca Power Tarom SOC
    ** per inverter

  • Product image

    Solarix PI 1200
    Solarix PI 1200

    Download

    Steca - Solarix PI Series.pdf (867.5 KiB)
