Description
The Steca PR 10-30 series of charge controllers is the highlight in the range. Use of the latest charging technologies combined with state of charge determination enable optimal battery maintenance and module power monitoring. A large display informs the user about all operating modes with the aid of symbols. The state of charge is represented visually in the form of a level meter. Data such as voltage, current and state of charge can also be displayed digitally as figures on the display. In addition, the controller has an energy meter which can be reset by the user.
→ High End State of Charge control (SOC)
→ Professional battery care
→ Full grafical display
→ Automatic battery voltage detection
→ Full load protection
Specification
Product No. R1001 Characterisation of the operating performance: System voltage 12 V (24 V) Own consumption 12.5 mA DC input side: Open circuit voltage solar module < 47 V Module current 10 A DC output side: Load current 10 A Reconnection voltage (SOC / LVR) > 50 % / 12.6 V (25.2 V) Deep discharge protection < 30% (SOC / LVD) < 30 % / 11.1 V (22.2 V) Battery side: End of charge voltage 13.9 V (27.8 V) Boost charge voltage 14.4 V (28.8 V) Equalisation charge 14.7 V (29.4 V) Set battery type liquid (adjustable via menu) Operating conditions: Ambient temperature -10 °C … +50 °C Fitting and construction: Terminal (fine / single wire) 16 mm² / 25 mm² - AWG 6 / 4 Degree of protection IP 31 Dimensions (X x Y x Z) 187 x 96 x 44 mm Weight 350 g → Technical data at 25 °C / 77 °F
→ Inverters must not be connected to the load output.
-
Product image
PR 1010 Download
