Description
The G-Cell 24V - 5,8kW LiFePo4 (lithium iron phosphate) battery is a leading product recognized by clients from North America, Europe and Australia. It is modular, light- weight and scalable for installations that range from kWh to MWh. G-Cell LiFePo4 pristamic cells features higher energy density, namely lighter in weight while higher in energy. This makes G-Cell lithium iron phosphate cells perfectly for home energy storage, commercial energy storage, etc.
- 24V LiFePo batteries with Battery Management System (BMS) do not require ventilation, cooling or thermal regulation.
- Long cycle life.
- Compatible with all Inverter/Charger & MPPT.*
- Replacement for lead acid batteries.
- LiFePo is the safest, most environmentally benign Lithium Ion chemistry available—no risk of thermal runaway or fire.
- No AC or toxic liquid cooling.
- Non-toxic and non-hazardous recyclable materials.* Inverter/Charger & MPPT must be programmable in charging values.
Specification
Product No. Nominal Voltage 25,6 V Nominal capacity 5,8 kWh Amp Hours 228 Ah Discharge Cut-Off 24 V Charge Current 60 A Cont. Discharge 60 A Peak Discharge 100 A (inst) Charge Temp. 0°C to 45°C Discharge Temp. -10°C to 55°C Life Cycle ≥8000 times Communication Built in BMS, no ext. comm. needed Weight 46 kg. Dimensions 41x25x42 cm. Warranty Period 15 Years Notes:
To max operating conditions: refer to warranty for recommended conditions.
Specifications are typical/nominal.
Subject to change without notice. -
Product image
C-Cell 24V 5,8kWh Download
